产品材质：
过流部件：铸铁、铝合金、不锈钢
非过流部件：铝合金
隔膜材质：三元乙丙橡胶、氟橡胶、Hytrel、氯丁橡胶、丁腈橡胶、山道橡胶、聚氨酯、PTFE
性能参数：
尺寸 ：1＂
流量 ：0 - 45GPM(170 LPM)
含固粒径 ：0.25＂(6mm)
扬程 ：125 PSI(8.6 BAR)
每冲程排量：0.11 gal(0.42 L)
常用型号：
M1FB1A1WABS000. M1FB1A2TABS000. M1FB1ABWABS000. M1FB1ACTABS000.
M1FB1AGTABS000. M1FB1AHWABS000. M1FB1AIWABS000. M1FB1ANWABS000.
M1FB1AZTABS000. M1FB1I1WABS000. M1FB1I2TABS000. M1FB1IBWABS000.
M1FB1ICTABS000. M1FB1IGTABS000. M1FB1IHWABS000. M1FB1IIWABS000.
M1FB1INWABS000. M1FB1IZTABS000. M1FB1S1WABS000. M1FB1S2TABS000.
M1FB1SBWABS000. M1FB1SCTABS000. M1FB1SGTABS000. M1FB1SHWABS000.
M1FB1SIWABS000. M1FB1SNWABS000. M1FB1SZTABS000. M1FB1A1WANS000.
M1FB1SGTANS000.
Material:
Wetted Material：Aluminum、Stainless steel
Non-Wetted Material：Aluminum
Diaphragm Materials：EPDM、FKM、Hytrel、Neoprene、BUNA、Santoprene、PTFE
Performance：
SIZE | 1＂ |
CAPACITY | 45GPM(170 LPM) |
SOLIDS-HANDLING | 0.25＂(6mm) |
MAXIMUM OPERATING PRESSURE | 125 PSI(8.6 BAR) |
DISPLACEMENT/STROKE | 0.11 gal(0.42 L) |
Models:
M1FB1A1WABS000. M1FB1A2TABS000. M1FB1ABWABS000. M1FB1ACTABS000.
M1FB1AGTABS000. M1FB1AHWABS000. M1FB1AIWABS000. M1FB1ANWABS000.
M1FB1AZTABS000. M1FB1I1WABS000. M1FB1I2TABS000. M1FB1IBWABS000.
M1FB1ICTABS000. M1FB1IGTABS000. M1FB1IHWABS000. M1FB1IIWABS000.
M1FB1INWABS000. M1FB1IZTABS000. M1FB1S1WABS000. M1FB1S2TABS000.
M1FB1SBWABS000. M1FB1SCTABS000. M1FB1SGTABS000. M1FB1SHWABS000.
M1FB1SIWABS000. M1FB1SNWABS000. M1FB1SZTABS000. M1FB1A1WANS000.
M1FB1SGTANS000.
